| General |
| Product code |
EXPI9400PT |
| Connectors |
RJ-45 |
| IEEE standards/network topology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Wiring |
Category-5, UTP, 4-pair |
| Adapter Product Features |
| Intel PROSet Utility and Intel PRO Intelligent Install
for easy installation |
* |
| Intel lead-free2 technology |
* |
| Plug and play specification support |
PIO mode 4/Ultra DMA 33 |
| Cache |
2 MB |
| Compatibility |
Standard |
| Auto-negotiation, full-duplex capable |
* |
| Integrated media access control (MAC) and physical layer
(PHY) |
* |
| Includes full-height and low-profile bracket options |
* |
| Cable distance |
100 m in Category-5 for 100/1000 Mbps; Category-3 for 10
Mbps |
| Network Management |
| Wired for management (WfM) baseline v2.0 enabled for
servers |
* |
| DMI 2.0 support, Windows Management Instrumentation
(WMI) and SNMP-manageable |
* |
| Remote Installation Services (RIS) |
* |
| Diagnostics (loopback, testability, PHY register access) |
* |
| Advanced configuration and power interface (ACPI) 1.0
power management |
* |
| Wake on LAN* support over PCI Express* |
* |
| PXE 2.0 enabled through boot read-only memory (ROM) |
* |
| Network Operating Systems (NOS) Software
Support |
| Microsoft Windows* Server 2003, Enterprise, Datacenter
(32- & 64-bit) |
* |
| Microsoft Windows 2000 |
* |
| Red Hat Linux* 2.4x or later (32- and 64-bit) |
* |
| FreeBSD 4.x or later |
* |
| Novell Netware* 5.x, 6.x |
* |
| Sun Solaris* x86, OS 8 and later |
* |
| SCO Open Server 5, OpenUNIX 8* |
* |
| Intel Backing |
| Limited lifetime warranty |
* |
| 90-day, money-back guarantee (U.S. and Canada) |
* |
| Advanced Software Features |
| Adapter fault tolerance (AFT) |
* |
| Switch fault tolerance (SFT) |
* |
| Adaptive load balancing (ALB) |
* |
| Fast EtherChannel*4 (FEC) |
* |
| Gigabit EtherChannel*4 (GEC) |
* |
| Teaming support |
Teaming support |
| Teaming support |
Supports 2 separate teams, maximum |
| IEEE 802.3ad* (link aggregation control protocol) |
* |
| Test switch configuration |
Tested with major switch original equipment manufacturers
(OEMs) |
| PCIe Hot Plug*/Active peripheral component interconnect
(PCI) |
* |
| IEEE 802.1Q* VLANs |
* |
| IEEE 802.3* (z, ab, u, x) flow control support |
* |
| TCP checksum offload X transmission control protocol
(TCP), user datagram protocol (UDP), Internet protocol (IP) |
* |
| IEEE 802.1p* |
* |
| TCP checksum/large send offload |
* |
| Interrupt moderation |
* |
| Technical Features |
| Data rate(s) supporter per port |
10, 100, and 1000 Mbps |
| Bus type |
PCI Express 1.0a |
| Bus width |
x1 Lane PCI Express, operable in x1, x4,x8, x16 slots |
| Bus speed (x1, encoded rate) |
2.5 Gbps uni-directional; 5 Gbps bi-directional |
| EEPROM-SPI and single EEPROM support |
* |
| Interrupt levels |
INTA |
| IEEE support |
802.3ab* |
| Hardware certifications |
FCC B, UL, CE, VCCI, BSMI, CTICK, MIC |
| Controller-processor |
Intel 82572GI |
| Typical power consumption |
3.3 W (3.3 V @ 1 A) |
| Operating temperature |
0-55 C |
| LEDs |
2 (1/port, link and speed) solid and blinking |
| Physical Dimensions |
| Length |
12.9 cm (5.1 in) |
| Width (standard bracket) |
2.2 cm (0.85 in) |
| Width (low-profile bracket) |
1.8 cm (0.725 in) |
| Height of full-height end bracket |
12.0 cm (4.725 in) |
| Height of low-profile end bracket |
7.9 cm (3.1 in) |
